4-20ma Passive Signal Isolator(Two In Two Out)

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

4-20ma Passive Signal Isolator(Two In Two Out)

DIN35 Rail 4-20ma passive signal isolator(two in two out)

Features:

Accuracy Grade:0.1/0.2
International standard input current signal:0-10mA/0-20mA/4-20mA
Standard current signal output:0-10mA/0-20mA/4-20mA
High linearity (non linearity<0.2%)
Have been calibrated, the user can use directly.
DIN35 Rail-mounted
Size:106.7x79.0x25.0mm
No power supply

Technical Specification

Part No.	Input Signal	Output Signal
DIN22 IAP0-10mA	0-10mA	0-10mA
DIN22 IAP0-20mA	0-20mA	0-20mA
DIN22 IAP4-20mA	4-20mA	4-20mA

Note: When you order, please note your part No.or details.

Note:

Before using, according to packing lists, and product labels, check the quantity, models and specifications
When measure the signal directly, please set the terminal tighten
There are no damaged insulation, conductive dust and corrosive fumes of metal in the environment
Installation pitch 10mm
We have adjusted well, do not adjust arbitrarily
Warranty: two years. But if clients damage products by themselves or tear off any labels on the product, we can not exchange
Products can not been used in strong magnetic field
Internal no anti-lightning circuit

Specifications subject to change without notice Warranty Two years (but violate operating rules and requirements to create damage, clients need pay maintenance costs) Copyright Copyright 2012 Shenzhen WAYJUN Industrial Automation Specifications subject to change without notice.

Download Datasheet : http://www.wayjun.net/Datasheet/Signal/DIN22%204-20ma%20no%20power%20converter.pdf
