8-CH DI/DO Ethernet switch to RJ45

Product Description

Keywords: switch digital to MODBUS TCP | switch to Web

WAYJUN WJ90-RJ45 is a Internet of Things and Industrial Ethernet acquisition module, to achieve the formation transparent between sensor and network. WJ90-RJ45 can send sensor data exchange to network, or send the data forwards network to the sensor.

Features:

• Eight digital inputs, eight digital output Industrial Ethernet I/O
• Supports Modbus TCP protocol
• Built-in Web feature, you can query level state by the web
• Switch output state can be set via the web
• No signal isolation between input, output and power supply
• Wide power supply range: 8 ~ 32VDC
• High reliability, easy programming, easy application
• Standard DIN35 rail mounting ,small size
• Users can set the module IP address and other parameters on the page
• Web login can be set account and password
• Dimensions: 120 x 70 x 43mm

Product Part No.:

• WJ90 - RJ45
• Communication Interface
• RJ45: RJ-45 output network interface
• WJ90-RJ45 General Parameters: (typical @ +25  Vs to 24VDC)

• Input type: digital signal input, 8 channels (DI0~DI7)

• Low level: input<1V

• High level: input 3.5~30V

• Input Resistance: 30KΩ

• Output type: open collector output, voltage 0~30V, maximum load current 30mA, 8-CH (DO0~DO7)

• Communication: MODBUS TCP communication protocol

• Web: support web to access module, support web setting module parameters

• Interface: RJ-45 network interface

• Power Supply: +8 ~ 32VDC wide range power supply, internal anti-reverse and over-voltage protection circuit

• Power Loss: less than 1W

• Operating Temperature: - 45 ~ +80


• Humidity: 10 ~ 90% (no condensation)

• Storage Temperature: - 45 ~ +80


• Storage Humidity: 10 ~ 95% (no condensation)

• Isolation Voltage: Non-isolated

• Dimensions: 120 mm x 70 mm x 43mm
