Modbus RTU to TCP , RS232/485 to Ethernet Module,

Product Description

MODBUS RTU to TCP, RS232/485 to Ethernet Module

(WJ102-232/485-RJ45 : Multifunctional serial server module)

Features:

• MODNUS RTU protocol is converted into MODBUS TCP protocol automatically
• 100M high-speed LAN, 10 / 100M adaptive Ethernet interface by itself
• Support AUTO MDI / MDIX, you can use a crossover cable or parallel cable connection
• RS232 baud rate can be set from 300-256000
• Working mode selectable TCP Server, TCP Client

UDP mode, UDP Server mode

• Supports virtual port mode
• Can across the gateway, across switches and routers
• Can work in LAN, you can also work on the Internet (extranet)
• Working port, destination IP address and port can be set easily
• Flexible serial data sub-frame is set to meet user demand for subcontracting
• Dimensions: 120 x 60 x 43mm

Product Overview:

WAYJUN WJ102-232/485-RJ45 is a industrial protocol converter between RS232/485 and TCP/IP. This server uses the TCP port network packets or UDP packets and RS232 or RS485 interface data to achieve transparent transmission, achieve transmission, serial servers so that you can easily connect serial devices to Ethernet and Internet, Network management of serial devices. And compared to similar products, its distinguishing feature is the stability of full-duplex, non-stop sending large amounts of data without losing a byte.

• Product Part No.: WJ102 - 232/485 - RJ45
• Communication Interface 2 RJ45:RJ-45 network interface
• Communication Interface 1
• 232/485:support RS232 or RS485 interface, choose suitable
• WJ102 General Parameters: (typical @ +25 , Vs to 24VDC)
• Transmission Distance: RS232----15 meters
• RS485-----1000m

Wires 200m (connect into the internet through the switch, unlimited distance)

• CPU: 32 bits ARM CPU
• Ethernet LAN: 10/100Mbps
• Protection: 2KV electromagnetic isolation
• Communication: Serial to Ethernet transparent transmission
• It can also be set MODBUS TCP to MODBUS RTU communication protocol.
• Web: support web to access module, support web setting module parameters
• Interface: RJ-45 network interface, RS232 interface or RS485 interface
• Power Supply: +8 ~ 32VDC wide range power supply, internal anti-reverse and over-voltage protection circuit
• Power Loss: less than 1W
• Operating Temperature: - 45 ~ +80

• Humidity: 10 ~ 90% (no condensation)
• Storage Temperature: - 45 ~ +80

• Storage Humidity: 10 ~ 95% (no condensation)
• Isolation Voltage: Non-isolated

Footprint Function:

Note: same name PIN interior are connected

More details,please check this download data sheet:

http://www.wayjun.net/Datasheet/Signal/WJ102%20-%20232485%20-%20RJ45%20EN.pdf
