0-24V to Differential signal isolated converter
Product Details:
Product Description
Differential signal/Pulse signal isolated Transmitter (three input three output)Features:
- Differential signal/Pulse signal isolated transmitters
- Support A, B, and Z three-phase differential simultaneous conversion
- 3 inputs, 3 outputs, selectable output pulse amplitude
- No change the original waveform frequency, response speed is over 500KHz
- Three-isolation :signal input/Power/signal output 3000VDC
- Power supply: 5V, 12V, 15V or 24V DC single power supply
- Low cost, high small size, ease of use, reliability
- Standard DIN35 rail mounting
- Dimensions: 120 mm x 70 mm x 43mm
- Industrial Temperature Range: - 45 ~ + 85
Application:
- Servo encoder signals to the PLC differential
- Pulse signal amplification and shaping
- Ground interference suppression
- Motor speed monitoring system
- Speed ¹measurement and alarm
- Signals without distortion transmission and transmission
| Signal input | Power | Signal output | |||
| input | code | Power | code | output | code |
|
|
| 24VDC | P1 | Output level 0-5V | O1 |
| Single signal input,peak value(Vp-p):5V | S2 | 12VDC | P2 | Output level 0-12V | O2 |
| Single signal input,peak value(Vp-p):12V | S3 | 5VDC | P3 | Output level 0-24V | O3 |
| Single signal input,peak value(Vp-p):24V | S4 | 15VDC | P4 | Open collector output | O4 |
| 5v differential pulse signal | S5 |
|
| Differential signal | O5 |
| User-defined | Su |
|
| User-defined | Ou |
Products Samples:
- Input: Encoder differential signal Power supply: 24V Output: 0-5V level
Type No.: DIN33 IAP-S5-P1-O1
- Input: Encoder differential signal Power supply: 12V Output: 0-24V level
Type No.: DIN33 IAP-S5-P2-O3
- Input: 0-5V level Power supply: 24V Output: 0-24V level
Type No.: DIN33 IAP-S2-P1-O3
- Input: 0-5V level Power supply: 12V Output: open collector
Type No.: DIN33 IAP-S2-P2-O4
- Input:0-24V Power supply: 24V Output: differential signal
Type No.: DIN33 IAP-S4-P1-O5
General Parameters:
| Name | Test Condition | Min. | Type | Max. | Units | ||
| Isolation voltage | 1min | 1500 | 3000 | | VDC | ||
| Signal input | Amplitude(Vp-p) | | 0.2 | 10 | 60 | V | |
| Frequency | | 0 | 10 | 500 | kHz | ||
| Input Resistance | | 10 | | | kΩ | ||
| Input Current | 5V input | | 0.45 | | mA | ||
| Signal output | Amplitude(Vp-p) | O1:output level 0-5V | | 5 | | V | |
| Frequency | | 0 | 10 | 500 | kHz | ||
| Voltage(high level) | O1:output level 0-5V | | 5 | | V | ||
| Voltage(low level) | | 0 | 0.05 | V | |||
| Current(high level) | | 2 | 5 | mA | |||
| Current(low level) | | 2 | 8 | mA | |||
| voltage | O4: Open collector output | | 5 | 30 | V | ||
| current | | 3 | 10 | mA | |||
| Response time | | | 1500 | | ns | ||
| Power supply | voltage | User-defined | 3.3 | 12 | 24 | VDC | |
| current | VD=12V | | 150 | | mA | ||
| Power loss | | | 2 | | W | ||
| Operation Temperature | | -45 | | 85 | ℃ | ||
| Storage Temperature | | -45 | | 85 | ℃ | ||
| | | | | | | | |
Footprint and wire diagram:
| PIN | Name | Description | PIN | Name | Description |
| 1 | OUT1+ | Signal output 1+ | 11 | GND1 | Signal input Ground |
| 2 | OUT1- | Signal output 1- | 12 | GND1 | Signal input Ground |
| 3 | OUT2+ | Signal output 2+ | 13 | NC | No connect |
| 4 | OUT2- | Signal output 2- | 14 | NC | No connect |
| 5 | OUT3+ | Signal output 3+ | 15 | IN3- | Signal input 3- |
| 6 | OUT3- | Signal output 3- | 16 | IN3+ | Signal input 3+ |
| 7 | NC | No connect | 17 | IN2- | Signal input 2- |
| 8 | NC | No connect | 18 | IN2+ | Signal input 2+ |
| 9 | PW+ | Power supply + | 19 | IN1- | Signal input 1- |
| 10 | GND | Power supply - | 20 | IN1+ | Signal input 1+ |
