0-5A AC to DC Signal Isolated Transmitter

Product Description

With enormous experience in this domain, we have established ourselves as the trusted manufacturer and supplier of highly efficient 0-5A AC to DC Signal Isolated Transmitter. It adopts the magnetic isolation technology and capable of inspection and monitoring of AC voltage signal. This is manufactured by making use of superior quality materials under the observation of our diligent team. In addition, this 0-5A AC to DC Signal Isolated Transmitter is available in different specifications at industry leading rates.

Features:

• Operational fluency
• High performance
• Low power consumption

Product List:

• DIN11 IAP 5AAC - P
• Power Supply Output Signal
• Power code current code voltage code
• 24VDC P1 0-20ma A3 0~5V V1
• 12VDC P2 4-20ma A4 0-10V V2
• 5VDC P3 User-defined Az 1-5V V6
• 15VDC P4 User-defined Vz
• 220VAC P5

• 1Input:0-5A Power supply:24V        output:4-20ma       Part No.:DIN11 IAP-5AAC-P1-A4
• 2Input:0-5A Power supply:220VAC output:4-20ma        Part No.:DIN11 IAP-5AAC-P5-A4 Features:

• Input Range:0~500mA~5AAC
• DC voltage/current signal output
• Isolation Voltage:2500VDC
• Accuracy: 0.5
• Installation: DIN35 rail mounted
• Industrial temperature range: - 40 ~ + 85 deg.C
