Differential signal/Pulse signal isolated Transmitter

Product Description

• Support A, B,and Z three-phase differential simultaneous conversion
•  3 inputs, 3outputs, selectable output pulse amplitude
• No change theoriginal waveform frequency, response speed is over 500KHz
• Three-isolation :signalinput/Power/signal output 3000VDC
• Power supply:5V, 12V, 15V or 24V DC single power supply
• Low cost, highsmall size, ease of use, reliability
•  Standard DIN35rail mounting
•  Dimensions: 120mm x 70 mm x 43mm
• Industrial Temperature Range: - 45 ~ + 85

• DIN33 IAP - P - O

Products Samples:

• Input: Encoder differential signal  Power supply: 24V   Output:0-5V level
• Type No.: DIN33 IAP-S5-P1-O1
•  Input: Encoder differential signal  Power supply: 12V   Output:0-24V level
•  TypeNo.: DIN33 IAP-S5- wer supply: 24V  Output: 0-24V level
•   Type No.:DIN33 IAP-S2-P1-O3
•  Input: 0-5V level  Power supply: 12V  Output: open collector

• Type No.:DIN33 IAP-S2-P2-O4
• Input:0-24V   Power supply: 24V  Output: differential signal

• Type No.: DIN33 IAP-S4-P1-O5
