Product Description

WEIXIN chat:15875565269

WAYJUN this product uses advanced isolated technology, quarantine inspection / monitoring DC voltage signal, small size,low power,high accuracy. Input/output/auxiliary power supply three isolation.Widely used in such fields as electricity, chemicals, petroleum, industrial and automatic control.
Selection Guide:
DIN12 IAP - V(A) - P - V/I

input signal				power supply		two output signal
voltage	code	current	code	Power	code	current	code	voltage	code
0-5V	V1	0-1mA	A1	24VDC	P1	0-20ma	A3	0-5V	V1
0-10V	V2	0-10mA	A2	12VDC	P2	4-20ma	A4	0-10V	V2
0-75mV	V3	0-20ma	A3	5VDC	P3	-20ma~+20ma	A6	1-5V	V6
0-2.5V	V4	4-20mA	A4	15VDC	P4	user-defined	Az	1~5V	V4
0~5V	V5	0-10mA	A5	user-defined	Pz			0~10V	V7
0-10V	V7	0-20mA	A6					user-defined	Vz
0-100mV	V10	user-defined	Az
user-defined	Vz

Samples:
1.Input:0-5V      Power Supply:24V Output:two 4-20mA    Type No.: DIN12 IAP- V1-P1-A4
2.Input:0-10V    Power Supply:24V Output:0-10V/4-20mA Type No.: DIN12 IAP-V2-P1-V2A4
3.Input:4-20mA Power Supply:24V Output:two 4-20mA     Type No.: DIN12 IAP- A4-P1-A4
4.Input:0-10V   Power Supply:24V Output:two 0-10V      Type No.: DIN12 IAP V2-P1-V2
